Portable Oil Purifier Machine / Multi Stage Filtration / High Precision Purification / Mechanical, Railway and Steel Industry
I. Application of PF series
NSH Portable Oil Purifier and Oil Filling Unit: NSH developed machine with more than three-stage precise filtering, greatly remove the impurities and particles from lubrication oils. It can achieve the functions of plate and frame filter press. It is also can serve as precise filtering and oiling.
II. Advantages of PF series
This machine is equipped with more than three-stage purification, portable, easy to operate, very competitive price, no need of purification paper, no contamination to the ground.Machine can effectively purify the tiny and fine mechanical impurity min oil, enabling it to be a prior choice of power industry, petroleum, chemical, metallurgy, mechanics and railway for oil filling, oil drawing and high precision impurity removal of mutual inductor, lathe, and oil breaker which do not use large quantity of oil.
III. Features of PF series
1. Easy to operate, low operation cost
2. Environmentally friendly, without secondary pollution.
3. Purify the tiny and fine mechanical impurities oil to remove the harmful materials.
4. A prior choice for high precision removing impurities.
5. With the function of oil filling & oil drawing.(for equipments required small quantity of oil).
6. Low production cost.
IV. Technical Specification
| Item | Unit | PF-30 | PF-50 | PF-80 | PF-100 | PF-125 | PF-150 |
| Flow Rate | L/H | 1800 | 3000 | 4800 | 6000 | 7500 | 9000 |
| Working Pressure | Mpa | ≤0.4 |
| Clearness | NAS | ≤6 |
| Height | m | ≥15 |
| Power Supply | | 380V/50Hz(or as needed) |
| Working Noise | dB(A) | ≤60 | ≤65 |
| Total Power | Kw | 0.75 | 1.1 | 1.5 | 1.5 | 2.2 | 2.2 |
| Pipeline Diameter | mm | DN25 | DN32 | DN32 | DN40 | DN40 | DN50 |
| Net Weight | Kg | 100 | 115 | 130 | 140 | 165 | 180 |
V. Relative Series:
VFD series: Insulation oil purifier System specialize in purifying branded oil, insulation oil of high voltage and super high voltage transformer. Additionally, it is suitable for treating low viscosity lubrication oil.
TF series: Turbine oil purifier system is particularly suitable for purifying turbine lubricating oil. It also applys to treat hydraulic, coolant oil and other lubrication in which contain large of water, vapor, impurities, sludge, dielectric and colloid. It can eliminate them effectively and efficiently.
LV series: Lubrication Oil Filter System are suitable especially for purifying and restoring hydraulic oil, machine oil, coolant oil and various other lubrication oil.
GER series: Used oil regeneration system is suitable to regenerate used internal-combustion engine oil including diesel engine oil, gasoline engine oil, and used hydraulic oil, other used lubrication oil of machinery.
GED series: it is used to recycle all kinds of waste oil into base oil or diesel oil with high quality.
